Refractory Mortar

INSULFIRE high temperature refractory mortar is a kind of new type of inorganic cementitious material made from powder of the same material by adding inorganic binder and agent after reaction. There are three grades of INSULFIRE high temperature refractory mortar say RM 1400, RM 1600 and RM 1750 available of different grades of masonry products.

Characteristics

High bonding strength, good overall masonry structure
Good air tightness, corrosion resistance and long service life
High load softening temperature and low shrinkage at high temperature
Good workability, high bond strength and small shrinkage after burning
Good slag resistance, small masonry mortar joint

Typical Chemical Properties

Item	RM-1400	RM-1600	RM-1750
Al₂O₃	35	43	55
SiO₂	59	51	40
Fe₂O₃	1.3	1.2	0.9
TiO₂	1.2	1	0.6
CaO + MgO	0.2	0.2	0.2
Na₂O + K₂O	2.8	2.8	2.3
Assorted Firebricks	B4、B5、YK23、YK26	YK28、YK30	YK32、AB96 、AB98

Physical Properties

Item	RM-1400	RM-1600	RM-1750
Classification temperature	1400℃	1600℃	℃1750
Max work temperature	1260℃	1500℃	1600℃
Color	Black	Black	Black
Density	1700kg/m³	1900kg/m³	2000kg/m³
Rupture Strength (110℃ after drying)	3.1MPa	3.5MPa	3.7MPa
Dry Shrinkage (110℃ after drying)	3.0%	2.5%	2.2%
Refractoriness	≥1600℃	≥1740℃	≥1760℃

Typical Application

Masonry of various industrial kilns
Bonding of refractory fiber blanket and felt

Dosage Advice:

200kgs for 1000 pcs of standard firebrick namely 230*114*65 mm for standard mortar joints say 2mm

The product is in slurry state at the time of supply
